The industry leader introduces the next generation of hydraulically driven ride-on power trowels.
The Whiteman series of hydraulic ride-on power trowels delivers a fresh new look plus all the features contractors demand from high-performance
finishing equipment.
State-of-the-art hydraulics eliminates gearboxes, clutches and belts to create the most reliable and trouble-free design ever.
These remarkable machines will help
improve your F-numbers and change the way you think about ride-on trowels. This high-performance
eight-foot class machine is powered by a 44-HP turbo diesel engine. With a top roto speed of 160-RPM this trowel
sets the standard for both ease of use and performance.
Electro-hydraulic pitch control enables the operator to simultaneously control blade pitch of both rotors with a simple rocker switch |
||||
Ergonically designed seat provides excellent support to help reduce operator fatigue Turbocharged engine provides Frame design provides operator Integral steps are provided Hydraulic drive motors for each rotor
|
 |
Proportional hydraulic steering helps the operator move the machine effortlessly across the slab Removable panels provide easy access to components for maintenance Tubular steel tank design improves flow and cooling of hydraulic fluid Lights are standard for illuminating night time and indoor work areas Retardant spray system Rotor Speed Control allows the operator to set the rotor speed and reduces the amount of foot pedal travel to relieve fatigue during low speed panning |
||
| Standard "Enduro" trowel blades last up to 50% longer than conventional blades | Operator's platform includes a built-in storage box for hand tools and accessories |
|||
|
||||
Model |
Engine |
Engine Cooling |
HP |
Blades Per Rotor |
Rotor RPM |
Path Width in (cm) |
Fuel Tank Capacity gal (litr) |
Run Time gal/hr |
L x W x H in (cm) |
Operating Weight lbs (kg) |
Wheel Kit |
|
Hydrostatic |
Twin 60" Non-Overlapping |
|||||||||||
| STX-551-6 | John Deere Turbo Diesel | Liquid | 55 | 6 | 10-130 | 117 (297) | 11 (42) | 2.81 | 125 x 65 x 57 (318 x 165 x 145) | 2270 (1030) | EMR3 | |
Twin 48" Non-Overlapping |
||||||||||||
| HTX-44-5
|
Turbo Diesel | Liquid | 44 | 5 | 10-160 | 92 (233) | 11 (42) | 2.36 | 95 x 48 x 57 (241 x 122 x 145) | 1855 (841) | EMR3 | |
